LHB13 RoLine features a robust plastic housing that is impact-resistant and capable of withstanding high-temperature water washing at 80°C, with pressures up to 100 bar (1450 psi). It operates within a power range of 20W to 60W, with an efficacy of up to 140 lm/W. The wide 120° beam, along with the optional honeycomb lens that provides medium beams of 60° or 90° to reduce glare (UGR < 16), makes it particularly suitable for food applications.
| Series Code | LHB13 |
|---|---|
| Power | 20W, 40W, 50W |
| Efficacy | 130lm/W, 140lm/W |
| Input Voltage | 220-240VAC, 100-277VAC, 50 / 60 Hz |
| Power Factor | >0.90 |
| Surge Protection | 1kV line-line, 2kV line-earth |
| UGR level | 19 |
| Control | DALI, 1-10V Dimmable, Dimmable |
| IP Rating | IP69K, IP66 |
| IK Rating | IK10, IK06 |
| CCT | 4000K, 5000K, 3000K |
| CRI(Ra) | 80, 70 |
| Operating Temperature | -30°C to + 40°C |
| Mounting Option | Pendant, surface, Wire Suspension, Ceiling Mounting |
| Warranty | 5 Years |
