BL03 14W/25W
BL03 has elegant cylinder housing, 360° emitting light and Type V distribution, making it to be ideal landscape lighting solution for beautifying environment and guiding pedestrian. Smooth surface helps it to be easily cleaned.
- 360° coverage and visual comfort.
- 14W, 25W in 0.5m or 1m height
- High output lumen efficiency up to 130lm/W
- 3 CCT adjustable
- 30%, 50%, 75% and 100% power adjustable
- 100% aluminum alloy ADC12 AL6063
Applications: Gardens, Pathways, Sidewalk, Building Entrance
Specification
- Series Code: BL03
- Power: 14W, 25W
- Efficacy: 110lm/W, 130lm/W
- Input Voltage: 220-240 VAC, 50 / 60 Hz
- Power Factor: >0.90
- CCT: 3000K, 4000K, 5000K
- CRI(Ra): 70, 80
- Control: Non-dim, Dimmable, DALI
- IP Rating: IP66
- IK Rating: IK10
- Mounting Option: Mounting kit with anchor bolts
- Warranty: 5 Years
- Surge Protection: 0.5kV line-line, 4kV line-line, 6kV line-earth
- Operating Temperature: -30°C to + 45°C
