| Item No. | HB02-100 | HB02-120 | HB02-150 |
|---|---|---|---|
| Optical Data | |||
| System Efficacy | 140lm/W | ||
| Luminous Flux | 14,000lm | 16,800lm | 21,000lm |
| Wattage | 100W | 120W | 150W |
| CCT | 3000K, 4000K, 5000K | ||
| CRI | Ra70, Ra80 | ||
| Electrical Data | |||
| Input Voltage | 100-240Vac / 100-277Vac | ||
| Input Surge Protection | 2kV line-line, 4kV line-earth | ||
| Power Frequency | 50/60Hz | ||
| Power Factor | >0.93 | ||
| Environmental | |||
| Ingress Protection | IP65 | ||
| LED Life Span | >180,000Hrs(Ta=30°C@L70) | ||
| Storage Temperature | -40°C to +70°C(-40°F to +158°F) | ||
| Operating Temperature | -40°C to +50°C(-40°F to +122°F) | ||
| Operating Humidity | 15-90%RH | ||
| Housing | Aluminum Alloy | ||
| Protection Class | Class I | ||
| Weight / Packaging | |||
| Luminaire Net Weight | 4.5±0.3kg (9.92±0.66Lbs) |
||
| Outlook Dimensions | φ310×310×169.5mm (12.2"×12.2"×6.67") |
||
| Export Carton Size | 360×360×215mm (14.17"×14.17"×8.46") |
||
| Series Code | HB02 |
|---|---|
| Efficacy | 140lm/W |
