HB59 DOB Driverless UFO High Bay Optimized Weight And Size Facilitate transportation and Storage

HB59 DOB Driverless UFO High Bay Optimized Weight And Size Facilitate transportation and Storage

HB59 DOB solution is a driverless UFO high bay solution. The compact design with optimized weight and size facilitates transportation and storage. What's more, make the lighting fixture easier to install and maintain. With the entry-level efficacy 120lm/W, it could be a replacement of 400W, 500W Halide, Metal Lamp, and HID. It comes with stable performance after a series of reliability tests, including drop test, thermal test, UV test, salt spray test, etc. This fixture will be a perfect choice for both wholesale and project channels in today's highly competitive market.

  • DOB solution, power selectable.
  • Cost-effective solution based on die-casting aluminum housing.
  • Multiple installations: loop hanging, ceiling mounting.
  • PC and ALU reflector are optional.
  • Compact design for three sizes. Operating temperature: -30°C to + 40°C.

Applications: For indoor lighting applications, Warehouse, Industrial Facility, Exhibition Center, Shopping Mall, Gymnasium, Toll Station and so on

* AGC products are designed for global market. Please contact our sales team for certification details.
* Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.
HB59 01
HB59 02
HB59 03
Series CodeHB59
Power100W, 120W, 150W, 200W
Efficacy120lm/W
Input Voltage220-240VAC, 50 / 60 Hz
Power Factor>0.95
Surge Protection2kV line-line, 4kV line-earth
UGR level29.5
IP RatingIP65
IK RatingIK08
CCT3000K, 4000K, 5000K
CRI70, 80
Operating Temperature-30°C to + 40°C
Beam AngleH00A59
Mounting OptionLoop Hanging, Ceiling Mounting
Warrantys5 Years
CertificationsCE, RoHS
